Vielo V+1
Gravel Bikes

On-road bike performance.
Gravel bikes with off-road capabilities.
Liberate your ride.

The Vielo V+1 Gravel Bikes have been a long time in the making - a product of ideas, theories and extensive know-how gained from thirty years working with some of the world’s most coveted ultra-performance cycle brands.Designed for British cyclist, the V+1 has not suffered compromises to meet the demands of global markets. Instead we have single-mindedly engineered the V+1 for riding on rough British roads plus off-road gravel tracks.We think of it as a go anywhere speed machine. But in reality, it’s much more than that.The V+1 is an exercise in painstaking attention to detail. A quest to find the perfect combination of compliance, stiffness and acceleration that helps British riders go where they want, as fast as they want.

V+1 (UD)

from £5,299.00

Vielo V+1 UD Carbon Gravel Bikes UK

V+1 UD Force Edition

  • Chain ring and crank: SRAM Force 1x 42Tooth
  • Rotors: SRAM Centre line R140mm F160mm (or up to180mm)
  • Brake lever / Shifter L: SRAM Force
  • Brake lever / Shifter R: SRAM Force
  • Brake caliper R SRAM Force post mount
  • Brake caliper F SRAM Force post mount
  • Rear Mech: SRAM Force 11sp Long cage
  • Chain: KMC DLC Black diamond 11sp
  • Cassette: SRAM X01 XG 1195 10/42
  • Saddle: Fabric Scoop Shallow Titanium Rail
  • Bottom Bracket: Token Press fit 30
  • Wheels: DT Swiss CR1600
  • Tyres: Schwalbe G-One Speed tubeless
  • Bar Tape: Fabric Silicon
  • Complete SRAM Force 1 Build kit
  • Vielo Carbon handlebar with 8 degree flair
  • Vielo Alloy stem
XSSMLXL
1SEAT TUBE415450482,5512,5540
2TOP TUBE HORIZONTAL505527,5545570592,5
3HEAD TUBE110130150170190
4CHAIN STAY HORIZONTAL422,5422,5422,5425425
5BB DROP555552,552,552,5
6SEAT TUBE ANGLE74,57473,57372,5
7FORK RAKE4848484848
8FORK LENGTH400400400400400
9HEAD TUBE ANGLE7070,57171,572
10WHEEL BASE1003,21017,51026,91044,61056,6
11REACH362,1373,8380,8394,2404,6
12STACK515,1535,9554,2575,1596,0
RIDER HEIGHT5’3”
▾
5’6”		5’5”
▾
5’9”		5’8”
▾
6’1”		6’
▾
6’4”		6’3”
▾
6’7”

*BB Height is based on 700c x 42mm tyre. BB Height will vary with tyre size.

V+1 UD frameset SRP £2,999

V+1 Force Edition with Carbon seat post SRP £5299
V+1 Force Edition with Dropper seat post SRP £5499

V+1 (UDG)

from £3,499.00

Vielo V+1 UDG Carbon Gravel Bikes UK

V+1 UDG Rival Edition

  • Chain ring and crank: SRAM Rival 1x 42Tooth
  • Rotors: SRAM Centre line R140mm F160mm (or up to180mm)
  • Brake lever / Shifter L: SRAM Rival
  • Brake lever / Shifter R: SRAM Rival
  • Brake caliper R SRAM Rival post mount
  • Brake caliper F SRAM Rival post mount
  • Rear Mech: SRAM Rival 11sp Long cage
  • Chain: SRAM PC1130
  • Cassette: SRAM XG 1150 10/42
  • Saddle: Fabric Scoop Shallow Cromo Rail
  • Bottom Bracket: SRAM GXP
  • Wheels: DT Swiss G1800
  • Tyres: WTB Riddler 700 x 37
  • Bar Tape: Fabric Silicon Black
  • Complete SRAM Rival 1 Build kit
  • Vielo Carbon handlebar with 8 degree flair
  • Vielo Alloy stem
XSSMLXL
1SEAT TUBE415450482,5512,5540
2TOP TUBE HORIZONTAL505527,5545570592,5
3HEAD TUBE110130150170190
4CHAIN STAY HORIZONTAL422,5422,5422,5425425
5BB DROP555552,552,552,5
6SEAT TUBE ANGLE74,57473,57372,5
7FORK RAKE4848484848
8FORK LENGTH400400400400400
9HEAD TUBE ANGLE7070,57171,572
10WHEEL BASE1003,21017,51026,91044,61056,6
11REACH362,1373,8380,8394,2404,6
12STACK515,1535,9554,2575,1596,0
RIDER HEIGHT5’3”
▾
5’6”		5’5”
▾
5’9”		5’8”
▾
6’1”		6’
▾
6’4”		6’3”
▾
6’7”

*BB Height is based on 700c x 42mm tyre. BB Height will vary with tyre size.

V+1 UDG frameset SRP £2,399

V+1 Rival Edition with Carbon seat post SRP £3499
V+1 Rival Edition with Dropper seat post SRP £3699

Road.cc

The V+1 gravel bikes simply glide over rough patches of broken tarmac. Nothing fazes them. Potholes, cracks, cattle grids, sunken drain covers – it handles them all so well.

Vielo V+1 Gravel Bikes Adventure

Live Ride Review

“I‘ve been riding road bikes where they shouldn‘t be ridden since the 80‘s. I’ve been testing professionally for over twenty years. I know when something is really special and the V+1 is certainly that.”

Guy Kesteven

Live Ride Review

“I‘ve been riding road bikes where they shouldn‘t be ridden since the 80‘s. I’ve been testing professionally for over twenty years. I know when something is really special and the V+1 is certainly that.”

Guy Kesteven

Live Ride Review

“I‘ve been riding road bikes where they shouldn‘t be ridden since the 80‘s. I’ve been testing professionally for over twenty years. I know when something is really special and the V+1 is certainly that.”

Guy Kesteven

Live Ride Review

“I‘ve been riding road bikes where they shouldn‘t be ridden since the 80‘s. I’ve been testing professionally for over twenty years. I know when something is really special and the V+1 is certainly that.”

Guy Kesteven

700 or 650b

There's room for both

1 bike with 2 wheel size options. V+1 gravel bikes have enough clearance for 700x42mm or 650b x 2.00”

Vielo V+1 Gravel Bikes Adventure & Road Performance
